Technical Information
|
|
Product Standard EN 15091 |
|
Manufacturer Warranty 2 Years |
|
Color / Finish Chrome |
|
Aearator Type M24X1 Male Threaded |
|
Flow Rate 7.5 - 9 Lt / Min (3 Bar) |
|
Operation Type Electronic and Sensor with Automatic Photocell Eyed |
|
Installation Connection Type Countertop |
|
Body Raw Material Brass |
|
Spout Length 120 mm |
|
Spout Height 120 mm |
|
Water Connection Flex Dimension 1/2"-3/8" |
|
Water Connection Flex Length 42.5 cm |
|
Dimension Of Base Rosette 55 mm x 55 mm |
|
Number Of Loom Holes For Assembly 1 |
|
Loom Hole Diameter Ø33±1 mm |
|
Max. Loom Thickness 40 mm |
|
Max. Performance Temperature 80°C |
|
Suggested Performance Temperature 60°C |
|
Max. Performance Pressure 10 Bar |
|
Suggested Performance Pressure 3 Bar |
|
Water Inlet (Hot - Cold) Single Inlet |
|
Photocell Faucet Energy Feed System Electric (220V / 12V) and Battery (6V DC Lithium Cell) |
|
Spout / Pipe Type Fix |
|
Product Total Height 140 mm |
